Blade Micrometer, Carbide-Tipp 1Inch, 0,4mm Blade

Blade Micrometer, Carbide-Tipp 1", 0,4mm Blade

Stock Code: MIT122-151
Next Day Delivery
£242.51 (exc VAT) EACH
£291.01 (inc VAT)
Includes your -15% Disc
Quantity: - +

Mitutoyo 122-151 Blade Micrometer This Digimatic Disc Micrometer allows you to measure a range of different materials. It offers you the following benefits: Non-rotating spindle and disc-shaped measuring surfaces. Measuring the root tangent length of spur and helical gears Measurable range of gear pitch: 0,5-6 module. Suitable for measuring felt, rubber, cardboard, fabric etc.

Range:
0 - 1 inch
Anvil/ Tip:
D
Accuracy:
±0.00015"
Mass:
275 g
Measuring force:
3 - 8 N
Graduation:
0.01 mm
Parallelism:
3 µm for models up to 75 mm (3+L/100) µm for models over 75 mm, L= max. range (mm)
Measuring spindle:
ø 8 mm, spindle pitch 0,5 mm
Delivered:
Including box, setting standard (from 25 mm upward), key
Inch-Metric:
Inch
