5 Flute V-Anvil Micrometer 45-65mm

Stock Code: MIT114-123
£482.80 (exc VAT) Each Includes your 15% Disc

£579.36 (inc VAT)

Next Day Delivery
Quantity:
-
+

Mitutoyo 114-123 Five Flute V-Anvil Micrometer This Digimatic Disc Micrometer allows you to measure a range of different materials. It offers you the following benefits: Non-rotating spindle and disc-shaped measuring surfaces. Measuring the root tangent length of spur and helical gears Measurable range of gear pitch: 0,5-6 module. Suitable for measuring felt, rubber, cardboard, fabric etc.

Range:
45 - 65 mm
Remarks:
-
Accuracy:
±6 µm
Setting standard:
167-331 ø 55 mm
Mass:
540 g
Measuring force:
5 - 10 N
Graduation:
0.01 mm
Flatness:
0,6 µm (spindle) 1,3 µm (anvil)
Measuring surfaces:
Prism angle 60°/108°
Measuring spindle:
With spindle lock, ø6,35 mm, spindle pitch 0,75 mm
Delivered:
Including box, setting standard, key
Digital/Analog:
Analog
Inch-Metric:
Metric
Functions:
For 5-flute cutting tools (108°)
