Digital Micrometer QuantuMike Inch/Metric, 3-4", w/o Output

Stock Code: MIT293-188
£301.75 (exc VAT) Each Includes your 15% Disc

£362.10 (inc VAT)

Next Day Delivery
Quantity:
-
+

Mitutoyo 293-188 This is a micrometer with a 2mm spindle pitch, offering movement four times as fast as a standard micrometer. The Digimatic Micrometer QuantuMike IP65 offers the following benefits: Faster measurement is achieved by using a coarser thread which feeds the spindle by 2mm per thimble rotation. It delivers approximately four times as fast as standard micrometer with 0.5mm spindle pitch. The device has outstanding accuracy, with only ±1µm instrumental error (75mm or less measuring range models). The dual function offered by the ratchet on the thimble and the fast drive mechanism ensure easy single-handed or stand operation. Excellent resistance against water and dust (IP65 protection level) enables this micrometer to be used in machining situations that include splashing coolant fluid.

Range:
3 - 4 inch
Accuracy:
±2µm/ 0.0001"
Mass:
620 g
Measuring force:
7 - 12 N
Digital step:
0,001 mm / 0,001 mm/0.00005"
Flatness:
0.3µm/.000012"
Parallelism:
1 µm for models up to 50 mm 2 µm for models up to 100 mm
Measuring surfaces:
carbide-tipped, precision round, micro-lap finish
Battery life:
approx. 2.4 years
Delivered:
Including box, key, 1 battery, setting standard (from 25 mm upward), certificate of inspection (0-50 mm range)
ORIGIN (until 100 mm):
Yes
ZERO/ABS:
Yes
Auto Power OFF after 20 min. non use:
Yes
Function lock:
Yes
HOLD:
Yes
Inch-Metric:
Inch/Metric
