Spline Micrometer 25-50mm, 3mm Measuring Face

Stock Code: MIT111-116
£167.45 (exc VAT) Each Includes your 15% Disc

£200.94 (inc VAT)

Next Day Delivery
Quantity:
-
+

Mitutoyo 111-116 Spline Micrometer This Digimatic Disc Micrometer allows you to measure a range of different materials. It offers you the following benefits: Non-rotating spindle and disc-shaped measuring surfaces. Measuring the root tangent length of spur and helical gears Measurable range of gear pitch: 0,5-6 module. Suitable for measuring felt, rubber, cardboard, fabric etc.

Range:
25 - 50 mm
Anvil/ Tip:
A
Accuracy:
±3 µm
Mass:
305 g
Measuring force:
5 - 10 N
Graduation:
0.01 mm
Flatness:
0,3 µm/0.000012"
Parallelism:
(2+L/100) μm, L = max. range (mm) [0.00008”+0.00004(L/4)]” L = max. range (inch)
Measuring surfaces:
carbide-tipped, micro-lap finish, stepped
Measuring spindle:
With spindle lock, Ø 6,35 mm, spindle pitch 0,5 mm
Delivered:
Including box, setting standard (from 25 mm upward), key
Digital/Analog:
Analog
Inch-Metric:
Metric
